| General Specification | VHF | UHF |
| Frequency Range | 134 - 174 MHz | 400 - 470 MHz; 450 - 520 MHz |
| Number of Channels | 16 |
| Power Supply Voltage | 7.4 V DC ±20% |
| Channel Spacing | 12.5/20/25 kHz |
| PLL Steps | 1.25 / 2.5 / 5 / 6.25 kHz | 5 / 6.25 kHz |
| Battery Life (5-5-90 duty)
2000 mAh FNB-V96LI |
15.5 hrs (13 hrs w/o saver) |
15 hours (12.5 hrs w/o saver) |
| IP Rating | IP 55 |
| Operating Temperature Range | -30ºC to +60ºC |
| Frequency Stability | ±2.5 ppm |
| RF Input-Output Impedance | 50 Ohms |
| Dimension (H x W x D) | 105 x 58 x 33 mm (w/FNB-96LI) |
| Weight (Approx.) | 310 g (w/FNB-V96LI, ANT, belt clip) |
