General Specification

VHF

UHF

Frequency Range

134 - 174 MHz

400 - 470 MHz; 450 - 520 MHz

Number of Channels

16

Power Supply Voltage

7.4 V DC ±20%

Channel Spacing

12.5/20/25 kHz

PLL Steps

1.25 / 2.5 / 5 / 6.25 kHz

5 / 6.25 kHz

Battery Life (5-5-90 duty)
2000 mAh FNB-V96LI

15.5 hrs (13 hrs w/o saver)

15 hours (12.5 hrs w/o saver)

IP Rating

IP 55

Operating Temperature Range

-30ºC to +60ºC

Frequency Stability

±2.5 ppm

RF Input-Output Impedance

50 Ohms

Dimension (H x W x D)

105 x 58 x 33 mm (w/FNB-96LI)

Weight (Approx.)

310 g (w/FNB-V96LI, ANT, belt clip)

Receiver Specification*

VHF

UHF

Sensitivity 12 dB SINAD

0.25 μV

Adjacent Channel Selectivity

65 / 60 dB

Intermodulation

65 / 60 dB

Spurious and Image Rejection

65 dB

Audio Output

500 mW @ 4 Ohms 5% THD

Transmitter Specification*

VHF

UHF

Output Power

5 / 1 W

Modulation

16K0F3E, 11K0F3E

Conducted Spurious Emissions

65 dB below carrier

FM Hum & Noise

45 / 40 dB

Audio Distortion

< 3 % @1kHz
